Hawaiian Electric Co. (HECO) has unveiled its proposed energy plan that would generate 65% of the electricity in its service areas from renewable sources by 2030, including a tripling of the amount of solar power deployed over current levels.

The plan was met with skepticism by solar sector advocates, particularly from installers of photovoltaic systems who have long expressed frustration with the logjam in interconnect approvals. Some of this frustration was manifest in a “candlelight vigil” for the solar sector, held outside of HECO’s offices in Honolulu, in anticipation of the utility plan. The Pacific Business News reports that solar installers in Hawaii see the HECO proposal as heralding the “inevitable” end of net-energy metering incentives.

HECO counters that its proposals will benefit the solar sector and customers alike. These include the following:

• A revised planning process to let customers and solar contractors know how much more solar can be added each year;
• Grid enhancements will make possible increased integration of solar power;
• Optimized control settings for solar equipment to improve safety and reduce the risk of power outages; and
• Expand use of energy storage systems - including batteries - to increase the ability to add renewables by addressing potential disruptions on electric grids caused by variable solar and wind power.



Trouble in paradise

The tension in Hawaii at the moment is between installers serving the distributed generation (DG) solar market for residential and light commercial customers and the utilities that must approve the interconnection of such projects. Solar supporters, such as the Alliance for Solar Choice, charge HECO is blocking interconnection applications for DG PV projects in order to protect a business model that relies on conventional central generation sources.

Others see the problem as more nuanced, with utilities struggling to incorporate levels of PV penetration that are far in excess of what was anticipated even a few years ago. Many of the incentives and essentially all of the interconnection policies have their origins in a time when solar energy was considerably more expensive. The dramatic drop in cost-per-watt PV prices due to massive increases in solar panel production - generally by manufacturers seeking to cash in on these government incentives - has swamped existing application procedures.

“As we see in Hawaii, you reach a point where you just can’t accommodate more PV without having to make significant upgrades to circuits,” says Sky Stanfield, an attorney with Keyes, Fox & Wiedman LLP who works on solar interconnection and regulatory issues. “The utilities want to - and legitimately need to - do more reviews as the number of PV systems increases on any one particular circuit.”

According to Stanfield, changes in interconnect procedures adopted by the U.S. Federal Energy Regulatory Commission and, subsequently, by several state authorities have resulted in the first significant improvements to such practices since PV began making itself felt. While this “Interconnect 2.0” scheme has shown definite benefits in streamlining applications through an expedited review process and still ensuring system safety and reliability, it is insufficient for handling the number and scale of PV interconnections envisioned in many state renewable energy plans.

“I think they are good changes,” says Stanfield. “But there is a lot more that needs to be done. We need to start thinking about Interconnect 3.0, which I think probably needs to be more transformative.”

In a sense, PV is a victim of its own success. The effect of adding significant amounts of intermittent renewable energy sources - and PV in particular - to the grid is perhaps nowhere more apparent than in Hawaii, with the essentially discrete grids of the individual islands. The disparity between loads and demands - both in terms of location and timing - is emerging as a key issue in the integration of intermittent sources on the grid.



Ahead of the curve

In a presentation at the PV America conference in Boston last June, Dora Nakafuji, HECO’s director of renewable energy planning, said one of the issues is that the utility’s demand peaks at night. The utility must occasionally issue advisories to its customers to conserve power in the evenings, particularly hot and humid ones in the summer, when light winds may all but becalm the island’s wind farms.

At the same time, most of the PV production occurs during the hours of 10 a.m. and 2 p.m., when fewer people are at home to use the power. This pattern results in a significant backfeed situation, where the amount of generation in local areas is more than the load.

The utility says backfeed threatens power quality locally, as well as grid integrity at the distribution level. Mitigation policies now in place utilizing currently available technology focus on automatically switching off PV systems before voltage spikes can damage utility or customer equipment. One option is to rely on inverter functions to do this. If the customer does not have an inverter with the required features, then PV users are asked to install an automatic transfer switch with the ability to meet the same tripping standard as the inverters.

The importance of this problem has prompted HECO to address it in its proposed energy plan. If approved, the utility would embark on a program of grid enhancements to produce state-of-the-art electric systems for its service areas on Oahu, Maui and Hawaii Island that will be able to make increased integration of solar power possible.

These improvements must be paid for. The issue of who will pay for them inevitably raises the issue of incentives for solar customers.

“Net-energy metering was originally envisioned to help customers offset some of their costs at the load,” Nakafuji said at PV America. “The net-energy metering program is almost too successful. We are getting a lot more interest in it. But because of the circuit penetration issues we are finding on our feeders, we basically are looking for ways to tailor the net-energy metering program so that it offers a bit more fairness to all the ratepayers, because not everybody can take advantage of net-energy metering.”

Such appeals to fairness are what prompt solar installers to interpret that the days of net-energy metering are numbered in Hawaii. However, it is also indicative of the new reality in power generation, where DG solar is an intrinsic part of a utility’s portfolio.

“We’re still fighting about just the valuation of solar,” Stanfield says. “It would be great if we could jump over this discussion and start thinking about the value of renewable resources and enabling technologies as deployed together.”

Stanfield says the U.S. is going to have to start doing bigger system upgrades technically and allocating costs in a different way if it is going to reach really high penetrations of PV. Storage, in particular, plays a significant role in HECO’s plans for a more robust, PV-acceptant grid.

“The interesting and more exciting part of that is starting to look at integration of other energy resources that can help mitigate and manage and achieve those, through the use of storage and command response and energy efficiency,” she says. S
